Drop fiber cable is specifically designed for FTTH (Fiber to the Home) indoor applications.
The optical fiber is located at the center of the cable, with two parallel strength members on both sides, and an outer protective sheath.
Product Features
- Excellent mechanical performance and temperature resistance;
- No grease filling inside the cable, making it easy to handle and install, and less likely to contaminate the installation site;
- Outer sheath materials offer corrosion resistance, water resistance, UV resistance, flame retardancy, and environmental friendliness;
- Tight-buffered fiber provides good flame-retardant properties and excellent resistance to bending and twisting.
|
Electrical Properties |
Physical Properties |
Environmental Conditions |
||||||||
|
Specification |
B1 (9/125 μm) |
Allowable Tensile Force |
Allowable Crushing Force |
Bending Radius |
Storage Temperature |
-30℃ ~+70℃ |
||||
|
Attenuation @20℃(dB/Km) |
Single-mode |
@1310≤0.4 @1550≤0.30 |
Long-term |
60N |
Long-term |
500N/100mm |
Dynamic |
20xD (D: Cable Diameter) |
Installation Temperature |
-10℃ ~+70℃ |
|
- |
- |
Short-term |
100N |
Short-term |
1000N/100mm |
Static |
10xD (D: Optical cable diameter) |
Operating Temperature |
-30℃ ~+70℃ |
|
|
Product Number |
Product Description |
Color |
Unit |
|
FD-PSW-1B |
GJXH-1B6a1 Steel Wire Reinforced Single-Core |
Black |
2km/reel |
|
FD-PSW-2B |
GJXH-2B6a1 Steel Wire Reinforced Cable, Single Core |
Black |
2km/Reel |
|
FD-PSN-1B |
GJXFH-1B6a1 FRP Reinforced Cable, Single Core |
Black |
2 km/reel |
|
FD-PSN-2B |
GJXFH-2B6a1 FRP Reinforcement Dual-Core |
Black |
2 km/reel |
|
FD-PSWZ-1B |
GJYXCH-1B6al Steel Wire + Self-Supporting Steel Wire Reinforced Cable |
Black |
2 km/reel |
|
FD-PSWZ-2B |
GJYXCH-2B6al Steel Wire + Self-Supporting Steel Wire Reinforcement |
Black |
2 km/reel |
