Product Details
|
Product Model |
FZS-120KW |
|
Product Name |
DC Charger for Electric Vehicles |
|
AC Input Voltage |
AC380V, Three-phase Five-wire System, Voltage Range: AC260~530V |
|
Grid Frequency |
45Hz~65Hz |
|
Rated Frequency |
50Hz/60Hz |
|
DC Output Voltage |
DC200V-1000V |
|
Voltage Regulation Accuracy |
<±0.5% (150-1000V, 0-20Hz) |
|
Current Regulation Accuracy |
≤±1% (Output Load 20%-100% Rated Range) |
|
Status Indication |
With Power, Running, Fault, three status indications |
|
Output Current Range |
0-250A |
|
Rated Output Power |
120KW |
|
Number of Output Channels |
Dual Channels, namely Gun A and Gun B |
|
Wiring Method |
Bottom In and Bottom Out |
|
Background Communication |
4G Network |
|
Payment Method |
APP Payment/QR Code Payment/Card Payment |
|
Display Screen |
7-inch LCD Touch Screen |
|
Metering Function |
Output Energy Metering |
|
Cooling Method |
Air Cooling |
|
Noise Level |
Not more than 65dB(A) (1m away) |
|
Operating Temperature |
-40℃~+75℃ |
|
Storage Temperature |
-40℃~+85℃ |
|
Installation Method |
Floor-standing |
|
Cabinet Dimensions |
2007257CM |
|
Protection Class |
IP55(Indoor/Outdoor) |
|
Altitude |
2000M |
|
Relative Humidity |
±95%RH, No Condensation |
|
Atmospheric Pressure |
79kPa-106kPa |
|
Implementation Standard |
GB/T18487.1-2015 |
|
Protection Functions |
Under-voltage Protection, Over-current Protection, Lightning Protection, Leakage Protection, Over-charge Protection, Short-circuit Protection, Over-temperature Protection, Rain Protection, Dust Protection, Flame Retardant Protection |
|
Charging Method |
Optional Card Swipe Start/Stop Charging, Plug-and-Play Charging, QR Code Charging and Prepaid Card Charging |
|
Application Scenarios |
Private Cars, Public Parking Lots, Shopping Centers, Residential Communities, Tourist Attractions, Charging Station Operators, Industrial Parks, Company Factories, Expressway Operators, etc. |
