Features

Standard 19-inch design; available for shipment in fully assembled or flat packed form;
Front and rear doors with an opening angle of ≥180°; multiple styles of front/rear doors are optional;
Multiple cable routing channels designed at the top and bottom; side doors feature a quick-releasing design; floor installation optiona include leveling feet, castors, or base plinth
Equipped with 2/4/6 fan sets on the top; power supply is optional;
2-4 cable ducts can be optionally configured according to cabling requirements, with multiple duct styles avaiable;
Optional accessories: fans, power distribution unit, trays, racks, keyboards, etc.

Primary Materials

19-inch rail: Aluminum-zinc coated sheet or electrophoretic coating; other components: High-quality SPCC cold-rolled steel sheet;
Thickness: 2.0mm-1.5mm-1.2mm

Degreasing, ceramization, pure water washing, electrophoresis, or electrostatic spraying;
Protection class: IP20;
Load capacity: Static load 600KG

Order Code	Capacity	Width	Depth	Height	Flat-packed Volume	Fully-assembled Volume	Weight
F8K■8818■■	18	800	800	987	0.322	0.632
F8K■8018■■	18	800	1000	987	0.34	0.790
F8K■8822■■	22	800	800	1164	0.372	0.746
F8K■8022■■	22	800	1000	1164	0.39	0.933
F8K■8827■■	27	800	800	1387	0.432	0.888
F8K■8027■■	27	800	1000	1387	0.45	1.110
F8K■8832■■	32	800	800	1609	0.494	1.030
F8K■8032■■	32	800	1000	1609	0.512	1.288
F8K■8837■■	37	800	800	1832	0.54	1.173
F8K■8037■■	37	800	1000	1832	0.576	1.466
F8K■8842■■	42	800	800	2054	0.616	1.315
F8K■8042■■	42	800	1000	2054	0.634	1.644
F8K■8847■■	47	800	800	2276	0.678	1.457
F8K■8047■■	47	800	1000	2276	0.696	1.822

F8K	F8KS	F8KQ	F8KP	F8KG	Color	Color	Optional accessories: fan assembly, shelf, bracket, power distribution unit, grounding wire, keyboard, door, etc.
Glued Door	Glued Patterned Glass Door	Replaceable Glass	Flat mesh Door	Angled Mesh Door	RAL9004	RAL7035
■	■	■	■	■	■■	■■
