Features
- Standard 19-inch design, integral welding structure, waterproof design, SECC;
- Seamless foam sealing strip on door panel, compatible with file boxes, switch panels, etc.
- Cabinet door can be modified to left or right opening per user requirements, interior mounting plate depth is adjustable
- The styles of the rain cover are optional and the cover is detachable, and the cabinet door lock and wiring hole can be customized;
- Optional fan unit, insulating cotton/panels, switch panels, and rodent-proofing devices
- Customizable optional rear doors, three-point locking, and raised bases; primarily tailored to specific requirements;
Primary Materials
- Premium SECC;
- Thickness: 1.5mm for mounting plate, 1.2mm for other components;
Surface Treatment
- Degreasing, ceramization, pure water rinsing, electrophoretic coating or electrostatic spraying
- Protection rating: IP66
- Load capacity: Static load 800KG
Outdoor Distribution Cabinet Order Code
|
Order Code |
Capacity |
Width |
Depth |
Height |
Weight |
|
FG6418 |
18 |
600 |
400 |
1000 |
|
|
FG6424 |
24 |
600 |
400 |
1200 |
|
|
FG6427 |
27 |
600 |
400 |
1400 |
|
|
FG6432 |
32 |
600 |
400 |
1600 |
|
|
FG6437 |
37 |
600 |
400 |
1800 |
|
|
FG6442 |
42 |
600 |
400 |
2000 |
|
|
FG6818 |
18 |
800 |
400 |
1000 |
|
|
FG6824 |
24 |
800 |
400 |
1200 |
|
|
FG6827 |
27 |
800 |
400 |
1400 |
|
|
FG6832 |
32 |
800 |
400 |
1600 |
|
|
FG6837 |
37 |
800 |
400 |
1800 |
|
|
FG6842 |
42 |
800 |
400 |
2000 |
|
|
Optional accessories: secondary door, insulation cotton or insulation panel, grounding copper busbar, etc. |
|||||
